Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - Day's Work Joint Repair April 1940. Extensive chipping necessary on Arch #40. Joint elevation 7296, centerline to 12' left in order to remove disintegrated concrete. Average depth of chipping 3.5 to 4 inches.
Type
Visual Materials(Opens in new tab)
Date
4/21/1940
Call number
photCL SCE 02 - 22873
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
