Big Creek, Huntington Lake Dams - Copy of Page 3 of Stone & Webster Report on Backfills on Dams at Huntington Lake: 4. Dam #1 - Badly disintegrated and porous concrete in vertical joint near station 5+66, elevation 690-4, after partial removal. Part of old repair plug in lower left center. 5. Dam #1 - Area near station 5+66, elevation 6904. Chipping in progress. Note two holes from which air escaped when applied to 4" drain through downstream backfill. 6. Dam #1. A second view of leak intakes near station 5+66, elevation 6904'. 7. Dam #1. Area near station 5+66, elevation 6904' after guniting.
