Big Creek, Florence Lake Dam

Description
Big Creek, Florence Lake Dam - View of spillway taken at 11:30 A.M., giving perhaps a little better view of spill over the drum gates (approx. 1 ft.) and the logs caught on top of same. In order to free the gates of these logs Mr. Panton, who was at the spillway at the time, lowered the gates just enough to allow these logs to be washed over. After this was done, which required only a short time, the gates were raised to their original position.
Type
Visual Materials(Opens in new tab)
Date
7/18/1927
Call number
photCL SCE 02 - 14367
Find out more
View in the Huntington Digital Library(Opens in new tab)
View in the Library catalog(Opens in new tab)
